KIP 870

  • 4 Rulolu Ağ Yazıcısı
  • 12" Smart System K Dokunmatik Ekranı
  • Standart Önden İstifleme
  • KIPFold için İsteğe Bağlı Arkadan İstifleme
  • KIP System K Print Management Suite
  • Windows ve AutoCAD Sürücüleri
  • İş Akışı Otomasyonu
KIP 870 professional printer
KIP 870 professional printer
KIP 870 professional printer
KIP 870 professional printer

Özellikler

Özellikler

Yeni bir kurumsal performans seviyesi!

KIP 870, yüksek proje gereksinimleri talebini ele almak üzere üstün bir performans ve güvenilirlik sunan bir çalışma grubu ve departman baskı sistemidir. Üretkenliği artıran çok yönlü arka istifleme veya katlama aksesuarlarıyla, kompakt ön istifleme tasarımını genişletin. Kullanışlı dokunmatik ekran, gelişmiş ağ bulut erişimi elde edilmesini ve bilgisayar iş istasyonu olmadan ayarlı baskı ve sistem yönetimi sunar. KIP 870 yazıcı ciddi zaman ve maliyet tasarrufu sağlar – Ultra yüksek kalitede geniş formatlı baskıyı hiç olmadığı kadar uygun maliyetli hale getirir. Daha hızlı yazdırılır. Daha basit çalışılır. Otomatik son rötuş yapılır. Güvenilirlik sayesinde sorunsuz çalışırsınız.

KIP 870 professional printer

Teknik Özellikler & Download

Teknik Özellikler & Download
General
2/4 Roll Colour and Black & White Printer

Colour and black & white printer with intelligent
KIP System K touchscreen

2/4 Roll Colour and Black & White Print/Copy/Scan Colour and black & white printer with intelligent Print/Copy/Scan KIP System K touchscreen for Print/Copy and Scan functions
Stacking Systems (standard) Front Stacking Print Tray
Description High production colour and black & white wide format print/copy/scan
Type LED Array Electro photography with organic photoconductor (OPC drum) Contact Development using non magnetic mono-component toner
Configurations Printer or multi-function system (print/copy/scan)
Speed Up to 268 sqm per hour in either black & white or colour regardless of image type or print resolution
Warm Up Time Instant from standby, less than 6 minutes from power on
Toner Four colour (CMYK), dry toner, print images are UV resistant and waterproof
Input Power EU/UK: 220 – 240 V, 50/60 Hz, 20 A
Power Consumption Ready: 0.6 kWh. Printing: 1.9 kWh, Warm Up: 3.4 kWh, Sleep Mode: 3 Wh
Acoustic Noise < 65 db Printing
Ozone < 0.05 ppm (average of 8 hours)
Dimensions (W x D x H) KIP 870: 1500 x 1080 x 1220 mm
Weight KIP 870: 530 kg
Printer
Print resolution 600 x 2,400 dpi
Paper capacity 280 sqm ( 2 rolls + cut sheet )
560 sqm ( 4 rolls + cut sheet )
Output sizes width (roll media) 297 mm – 914 mm
Output sizes length (roll media) 210 mm minimum, 64 m maximum (actual length may be dependent on media type and file type limitations)
Paper weight (roll media) Bond: 67 – 150 gsm, Film: 3 – 4 mil Double Matte Polyester, Tracing: 67 – 75 gsm
Banner and Gloss: see KIP 800 Media Guide
Sheet Bypass Up to 150 gsm bond / Maximum sheet size
914 mm x manageable length / Minimum sheet size A3
Media types Bond Paper: Economical Bond, Standard Bond. Specialty
Bond paper: Presentation Bond, Heavy Weight Bond.
Polyester Film: 3 mil Clear, 3 mil Double Matte, 4 mil
White Opaque. Banner Media: Fusion Soft Polyester.
Please see the KIP 800 Series Media Guide for details.
Scanner / Copier
Resolution 600 dpi (optical)
Original Single Sheet, image viewable / face up
Widths 210 mm – 914 mm (international standard page sizes to include ANSI, ARCH, ISO A & B, CHN, JPN)
Length 210 mm – 6 m
  Please see the KIP 2300 Scanner documentation for details on this optional scanner for the KIP 890 Colour System
Controller
Controller Type System K Embedded, Windows Standard Embedded
7 – 64 bit, i5 Quad Cord (min)
Memory 4 GB (min)
Compatible File Formats Raster Colour: TIFF, JPG, JPG2000, PNG, BMP, GIF, TGA, RLE/RLC
Vector Colour/B&W: HPGL, HPGL/2, HP-RTL, Postscript (PS/EPS), Adobe PDF, Autodesk DWF, Multipage PDF & DWF
Raster B&W: TIFF Group 3 & 4, CALS Group 4, Grayscale TIFF
Vector B&W: Calcomp 906/907
Space, Electrical & Environmental Requirements
Total Space (minimum) 3350 x 2600 mm (W x D)
3350 x 5190 mm (W x D) (with optional rear print stacker)
Electrical Requirements EU/UK: 220-240 V, 50/60 Hz, 16 A
Electrical Receptacle Europe = CEE 7
UK = BS 546
All other regions = please refer to your local standards
Network Port RJ-45 port-CAT5 or higher. LAN rated at least at 100 MB.
Recommended is 1000 MB
Room Temperature 10 – 30°C
Humidity 15 – 80% RH
Site Survey KIP 800 Colour Series site survey documentation is to be completed prior to system installation

  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • Konica Minolta does not warrant that all specifications mentioned will be error-free.
  • Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
  • All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
